Brand Name : Shenzhen LED World
Model Number : LW-FI 3
Certification : RoHS,FCC,CCC,CE
Place of Origin : China
MOQ : 1 square meter
Price : negotiable
Payment Terms : T/T, Western Union, MoneyGram
Supply Ability : 2000 square meter /Month
Delivery Time : 12~18 days after receiving the deposit
Packaging Details : Plywood cartons or wooden case
Pixel Pitch : 3mm
Pixel Configuration : 1R1G1B
Scan Method : 1/16
Cabinet Weight : 9.2Kg/cabinet
Signal Input Source : VGA, DVI, HDMI, SDI, HD-SDI
Working Temperature : -20-+50 degrees celsius
Cabinet Material : Die-casting Aluminum
Module Resolution : 128x64
Brightness : 2500CD/M2
Best View Distance : >3m
High Brightness 3mm HD Indoor Fixed LED Display with VGA DVI HDMI SDI HD - SDI input
Quick detail:
Pixel pitch:3mm
LED Screen cabinet:768x768mm iron cabinet
LED Screen size: width 6.144 m , height:3.072 m
Quantity:48 pcs cabinets
Location:Philippines
Date:28th March 2017
Application:
Specification:
| Item | Parameter |
| Model NO. | P3 |
| Pixel Pitch | 3mm |
| Pixel Configuration | 1R1G1B |
| Density | 111111dots/m2 |
| Brightness | 2500CD |
| Color Temperature | 6500-9500K |
| Scan Method | 1/16 |
| Cabinet Size | 768x768mm |
| Module Resolution | 128x64 |
| Cabinet Resolution | 256x128 |
| Cabinet Weight | 9.2Kg/cabinet |
| Max. Power Consumption | 1350W/m2 |
| Ave. Power Consumption | 700W/m2 |
| Best View Angle | H:120 Degrees, V:120 degrees |
| Refresh Rate | 960Hz |
| Gray Scale | 16bit |
| Best View Distance | >3m |
| Protection Level | IP31 |
| Cabinet Material | Die-casting Aluminum |
| Operation Voltage | 110-220V AC 50-60Hz |
| Working Temperature | -20-+50 degrees celsius |
| Working Humidity | 10%-90% |
| Signal Input Source | VGA, DVI, HDMI, SDI, HD-SDI |
| Control Distance | Ethernet cable:100m, Multi-mode optical fiber:500m,singel-mode optical fiber:20Km |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |
